• FM Cost Trends

    Industrial buildings.

    May 26, 2015
    2 min read
    Untitled Document

    Steel Manufacturing Facility

    This 26,000-square-foot light industrial facility showcases the creativity of the steel manufacturer occupying it, from the curved steel roof to the steel reception desk. The two-floor structure features poured concrete columns and beams with a steel frame structure. The foundations are reinforced concrete with slab-on-grade, while exterior wall finishes are veneered with cultured stone and metal.

    Office and shop spaces alike benefit from clerestory windows and plenty of insulation. A carefully planned site and staging area help move raw materials through the manufacturing process.



    Green Manufacturing Center

    Environmental innovation earned this light manufacturing facility LEED Gold certification. The 8,000-square-foot office space and 34,000-square-foot manufacturing, shop, and storage area are linked by a wall-to-wall window that illustrates the company’s dual nature. The conference room is insulated with straw bale walls that provide an R-value of 42. Low-tech earth tubes naturally cool air in the shop by passing it under the building, while large fans draw hot air up and through clerestories. A 189 kW solar system will soon allow the property to produce 90% of its own energy needs. Vegetated swales account for all infiltrated stormwater mitigation on site.

    View Larger

    View Larger

    For more facilities cost data, visit the BUILDINGS bookstore at www.bnibuildings.com.
    Additional building case studies are available at DCD.com

    *Actual building costs have been adjusted to reflect materials prices as of January 2015
    SOURCE: DESIGN COST DATA, BNI
